Graphalgo Malware Targets Go Modules and Terraform Providers

· Original article ↗

Summary

Researchers found Graphalgo-related Go malware in two Terraform providers and two Go modules. The malware uses conditional execution and Slack and blockchain C2; the article details its operation, indicators, and response guidance.

Key points

  • The malware was found in Terraform providers gocommunity-io/dockerd and kreuzwenker/docker, and Go modules gocommunity[.]io/orderedbtree and gogets[.]dev/btreex.
  • The Terraform providers activate only when specified input values produce a particular SHA256 hash; Go module variants also use conditional activation.
  • The providers decrypt an embedded archive and execute its contents as Go code; one Go module conceals its payload in a ZIP archive disguised as a SQL file.
  • The second-stage Go RAT uses Slack and an Ethereum smart contract on Arbitrum Sepolia for C2, with encrypted, client-specific communications.
  • Researchers linked the malware to the Graphalgo NPM campaign through shared infrastructure and a public key. The actor also created fake Go package ecosystems to promote malicious packages.
  • The article recommends isolating affected machines, rotating credentials, reviewing activity, and reimaging systems where the packages ran.

Article Details

Attack Vectors
  • Malicious Go Modules and Terraform providers distributed Go malware; one provider was a typosquat of a popular Terraform provider.
  • The provider payload activates only when specified Terraform variable values produce a particular SHA256 hash; the Go Module variant also required specially crafted input.
  • The malware decrypts files concealed in ZIP archives and executes the resulting Go code. Its second stage can execute additional Go or JavaScript code.
  • The second-stage agent uses Slack and an Ethereum smart contract on the Arbitrum Sepolia testnet for command and control.
Defensive Notes
  • Alert on HTTP-based blockchain service communications where there is no business need for blockchain access.
  • If an affected package or provider ran on a developer machine or CI/CD runner, isolate the environment, rotate credentials that accessed it, review activity during the exposure window, remove the package, and reimage the machine.
  • For Terraform-provider exposure, prioritize cloud and infrastructure credentials; also review commits, package publishes, Terraform applies, and GitHub Actions runs made from the affected machine or with its credentials.

Indicators of compromise

TypeIndicatorContext
DOMAINgocommunity[.]ioFake Go package ecosystem website associated with a threat actor-controlled organization and reportedly used to lend legitimacy to malicious packages.
DOMAINgogets[.]devFake Go package ecosystem website associated with a threat actor-controlled organization and reportedly used to lend legitimacy to malicious packages.
SHA2565f892a5424e88a21a3eb3d7f82ebf04d8ac31cdb19ada25153be4165df977d0fSHA256 of the malicious archive distributed in both Terraform providers.
SHA256ab01686d87565250fc4989faddb877d793667b07ec217a61cbd798f5695d62f5SHA256 of the ZIP archive masquerading as a SQL file in the malicious gogets.dev/btreex Go Module.
URLhxxps[:]//portfolio-devs[.]slack[.]comSlack workspace used by the malware for C2 check-ins; the article notes the malware communicates with api.slack.com rather than directly contacting this workspace subdomain.
URLhxxps[:]//portfolio-testers[.]slack[.]comSlack workspace used for subsequent C2 communications; the malware communicates through the Slack API rather than directly contacting this workspace subdomain.

MITRE ATT&CK

T1027 · Obfuscated Files or InformationThe provider payload was hidden in a compressed archive, and its files were AES-encrypted.T1036.005 · Match Legitimate Resource Name or Locationkreuzwenker/docker was identified as a typosquat of the popular kreuzwerker/docker Terraform provider.T1036.008 · Masquerade File TypeMalicious ZIP archives were disguised with the filenames import-resource.sqlite3 and btreex.sql.T1041 · Exfiltration Over C2 ChannelThe malware sends collected system information to a Slack C2 channel.T1059 · Command and Scripting InterpreterThe malware executes decrypted Go code with a detached go run command and accepts C2 instructions to execute additional Go code.T1059.007 · JavaScriptC2 instructions can direct the malware to execute JavaScript using node.T1070.004 · File DeletionC2 messages can instruct the malware to self-delete.T1082 · System Information DiscoveryThe malware collects system attributes including hardware, OS, hostname, architecture, and node availability.T1102.001 · Dead Drop ResolverThe malware retrieves encrypted instructions and key material from an Ethereum smart contract used as a blockchain dead drop.T1102.002 · Bidirectional CommunicationThe malware uses Slack workspaces and the Slack API for bidirectional C2 communications.T1140 · Deobfuscate/Decode Files or InformationThe malware AES-decrypts the archive contents before executing them as Go code.T1195.001 · Compromise Software Dependencies and Development ToolsMalicious Terraform providers and Go Modules distributed the Go malware through software dependencies.T1573.001 · Symmetric CryptographyThe malware encrypts C2 communications using a shared key derived from ephemeral key material and threat actor public keys.
