QuickFox Supply-Chain Attack Deployed FDMTP Implant on Windows Systems
Summary
FortiGuard Labs detailed a QuickFox supply-chain compromise that delivered an FDMTP implant to selected Windows users. QuickFox removed the malicious components from its Windows installer in version 3.59.6 after Fortinet's notification.
Key points
- Trojanized Windows installers modified an Electron HTML file to run JavaScript loaders that downloaded and installed the FDMTP implant.
- Fortinet identified affected Windows versions from 3.51.0 through 3.59.5; QuickFox removed the malicious components in version 3.59.6.
- The malware used process checks to select targets, stopping if Steam was running and requiring at least one process from a list of business, developer, translation, or crypto applications.
- The implant used DLL sideloading through the legitimate csmonitor.exe binary and communicated with FDMTP command-and-control infrastructure.
- It collected host and process information and supported remotely delivered plugins; Fortinet observed little post-install activity beyond initial enumeration.
- Fortinet found technical and infrastructure overlaps with a campaign previously reported by Darktrace, but did not confidently attribute the QuickFox campaign to a specific actor.
Article Details
- Attack Vectors
- A trojanized application installer included two added JavaScript lines in an embedded Electron renderer HTML file, causing initialization to download and execute a loader from masquerading infrastructure.
- The initial loader restricted execution to Windows, stopped when steam.exe was running, and downloaded the next stage only when at least one of 26 selected application processes was present.
- Downloaded archives combined a legitimate executable with a malicious DLL for sideloading. The first loader generation embedded the implant; the second decrypted an adjacent encrypted payload file.
- The implant registered with a staging server, retrieved cluster addresses, and established a separate socket-based command channel.
- Server-delivered plugins were stored in the registry, decompressed and loaded on command. An analyzed plugin could download additional executable files for subsequent execution.
- Defensive Notes
- The source reports removal of malicious Windows installer components in version 3.59.6, first observed on 2026-06-29. Other passages instead cite 3.55.6 as the remediation boundary; the article therefore contains inconsistent version guidance.
- Available historical installers were not an exhaustive set. Modified HTML also appeared in some Mac builds, but Windows-only execution checks prevented infection progression there; corresponding initial infection behavior was not observed in iOS or Android builds.
- Evaluate process lineage through the application's Electron child process. Numerous application child processes are not inherently malicious, whereas the loader's repeated cmd.exe invocations warrant contextual investigation.
- Obfuscated JavaScript alone is not anomalous in an Electron application; assess its download behavior, execution checks, and infrastructure relationships.
- Fortinet reports antivirus signatures, malicious URL ratings, and IP reputation protections associated with this investigation. The source states that supported products with current protections protect customers.
- FortiGuard Labs observed no significant post-exploitation activity beyond the reported enumeration and plugin functionality, limiting confidence in attribution and ultimate targeting.
Indicators of compromise
| Type | Indicator | Context |
|---|---|---|
| DOMAIN | 51quickfox[.]cn | Unofficial lookalike domain associated with the malicious QuickFox delivery host. |
| DOMAIN | cdns3[.]51quickfox[.]cn | Malicious QuickFox lookalike host delivering initial scripts and payload archives. |
| DOMAIN | www[.]google-apis[.]net | FDMTP staging and registration domain that also hosts implant components. |
| DOMAIN | www[.]icloud-cdn[.]net | FDMTP staging and registration domain providing cluster connection details. |
| DOMAIN | www[.]techcheck1[.]com | FDMTP staging and registration domain that also hosts implant components. |
| DOMAIN | www[.]wangmeng[.]xyz | FDMTP staging and registration domain providing cluster connection details. |
| DOMAIN | www[.]wangmeng66[.]top | FDMTP staging and registration domain providing cluster connection details. |
| DOMAIN | www[.]wangmengsb[.]com | FDMTP staging and registration domain providing cluster connection details. |
| DOMAIN | www[.]yahoo-cdn[.]it[.]com | FDMTP staging, registration, and payload infrastructure. |
| IPV4 | 103[.]231[.]15[.]135 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 103[.]231[.]15[.]219 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 103[.]231[.]15[.]248 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 103[.]246[.]244[.]13 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 103[.]246[.]244[.]20 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 123[.]254[.]105[.]38 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 123[.]254[.]106[.]148 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 154[.]223[.]24[.]158 | Address identified for the FDMTP staging host www[.]icloud-cdn[.]net. |
| IPV4 | 154[.]223[.]54[.]159 | Address identified for the FDMTP staging host www[.]icloud-cdn[.]net. |
| IPV4 | 154[.]223[.]58[.]142 | FDMTP C2 cluster node. |
| IPV4 | 154[.]223[.]58[.]64 | FDMTP C2 cluster node. |
| IPV4 | 154[.]223[.]75[.]206 | FDMTP C2 cluster node. |
| IPV4 | 170[.]33[.]128[.]5 | Address identified for the FDMTP staging host www[.]icloud-cdn[.]net. |
| IPV4 | 202[.]181[.]25[.]71 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 202[.]181[.]25[.]73 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 38[.]60[.]142[.]56 | FDMTP C2 cluster node shared by identified staging domains. |
| IPV4 | 43[.]240[.]12[.]34 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 43[.]240[.]12[.]35 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]15[.]100 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]15[.]104 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]15[.]111 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]15[.]114 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]15[.]115 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]225 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]226 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]227 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]229 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]230 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]231 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]232 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]233 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]234 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]235 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]125[.]35[.]236 | Address identified for the FDMTP staging host www[.]wangmeng66[.]top. |
| IPV4 | 45[.]158[.]180[.]250 | FDMTP C2 cluster node. |
| IPV4 | 47[.]238[.]240[.]219 | FDMTP C2 cluster node. |
| IPV4 | 47[.]238[.]64[.]56 | FDMTP C2 cluster node. |
| IPV4 | 47[.]239[.]4[.]179 | FDMTP C2 cluster node linked to multiple staging domains. |
| IPV4 | 47[.]239[.]93[.]49 | FDMTP C2 cluster node. |
| IPV4 | 47[.]76[.]92[.]73 | Address identified for the FDMTP staging host www[.]icloud-cdn[.]net. |
| IPV4 | 47[.]83[.]122[.]51 | Address identified for the FDMTP staging host www[.]icloud-cdn[.]net. |
| IPV4 | 47[.]86[.]14[.]22 | Address identified for the FDMTP staging host www[.]icloud-cdn[.]net. |
| IPV4 | 47[.]88[.]21[.]252 | FDMTP C2 cluster node. |
| MD5 | 03fd832b81dd54d2bf5f610a8ff27856 | Generation 2 Microsoft.ServiceHosting.Tools.dll FDMTP loader. |
| MD5 | 19e760ee849eb7c1f100f2b7010a763d | Additional encrypted FDMTP payload sample in the host IOC table. |
| MD5 | 1f3031167f94b166cc7b69376a01c124 | config.bin FDMTP payload artifact. |
| MD5 | 2dd8681dcd218c88d1c78dfe939ec92b | Generation 2 FDMTP loader associated with config.bin. |
| MD5 | 30d59c3d4916aa5fb24050c6aae7f8e4 | update.zip archive containing the generation 1 FDMTP loader and sideloading executable. |
| MD5 | 3b79d95f7f7b58c401a3bc79f94ebb52 | Source-listed hash of the generation 1 Microsoft.ServiceHosting.Tools.dll FDMTP loader. |
| MD5 | 5e4ed6abbf555e5a542e3d4308ccd7bf | Encrypted FDMTP payload stored in update.bin. |
| MD5 | 5f3daf7417dd666213168eb6c7453cc7 | Additional campaign artifact explicitly listed in the host-based IOC table. |
| MD5 | b1d344c9a1525373be6a3980fa85a603 | Additional campaign artifact explicitly listed in the host-based IOC table. |
| MD5 | e0a92209dd62dae8460d934dc6b7ddd7 | update.zip archive containing the generation 2 FDMTP loader, payload, and sideloading executable. |
| SHA1 | 11a6df1e15663ae89f59a9e598ae8987f42a632b | Additional campaign artifact explicitly listed in the host-based IOC table. |
| SHA1 | 173dd4190740b96f6f733c801b6428ed4b52b607 | Generation 1 Microsoft.ServiceHosting.Tools.dll FDMTP loader. |
| SHA1 | 2cc0425a90a39ac4eedadd59caaafad5b50f8420 | update.zip archive containing the generation 2 FDMTP loader, payload, and sideloading executable. |
| SHA1 | 3449a349b6c8045b16df4f88d58c65c2bdf891bb | Additional encrypted FDMTP payload sample in the host IOC table. |
| SHA1 | 7ab7ffe4c233a4f2440f0fdeb2e117c788792281 | Generation 2 Microsoft.ServiceHosting.Tools.dll FDMTP loader. |
| SHA1 | a195810c41f401c4b48cb557cf8ce60c2d807025 | update.zip archive containing the generation 1 FDMTP loader and sideloading executable. |
| SHA1 | b194a997c9a653134bdb1f2d0c3137dcdacb54d5 | config.bin FDMTP payload artifact. |
| SHA1 | b370b674ce877b9c0a7708c7834aeb7eda983564 | Encrypted FDMTP payload stored in update.bin. |
| SHA1 | c41b4e11e6a9e3b53da1f92b213de9f65a825c92 | Generation 2 FDMTP loader associated with config.bin. |
| SHA1 | e90d2730f3354ff1adf334b03c95eac3207d47b9 | Additional campaign artifact explicitly listed in the host-based IOC table. |
| SHA256 | 2b6cdafdfe427a3de1a94a8a2ca1f09fc4c8f90e4f59089fd9b35b73185ed01c | Generation 1 Microsoft.ServiceHosting.Tools.dll loader with an embedded FDMTP payload. |
| SHA256 | 3bd3b300f3278520819a06d0cb1f0eadbf946dbbc11352538246ff075eb427f1 | Additional campaign artifact explicitly listed in the host-based IOC table. |
| SHA256 | 5cbb64375636e83b5f17d6083633cecc02e2a5f4168cd7cca5cdee36ccca9b38 | Additional encrypted FDMTP payload sample in the host IOC table. |
| SHA256 | 6634339b813e6105b5138de6ab67b016b8dfbf49233c29de9bab3207e8b50d24 | Generation 2 loader that decrypts and reflectively loads config.bin. |
| SHA256 | 6932a20ac61fd3f93d7cfee414f6f46834068ac7c9ca011b054a6a10dc56b3d1 | Additional campaign artifact explicitly listed in the host-based IOC table. |
| SHA256 | 7462ce2595119c928cf516ec33148dc2a39dd9f71636a5c849c7ed93b7c5ca06 | update.zip archive containing the generation 2 FDMTP loader, payload, and sideloading executable. |
| SHA256 | 795594ad5e6f2868cc4d8ed12dabf4f3999a1477c6b250527c5ede9a98528fb9 | Generation 2 loader that decrypts and reflectively loads update.bin. |
| SHA256 | a53d756f28457b1c4a239c91cdec8ed7b7da67a93e332e6df9621cbef8417474 | config.bin FDMTP payload artifact. |
| SHA256 | d9db5cbc193ddaf4c0a265804fdef70c32451daaf2974fa9adf52ce1defac5f7 | update.zip archive containing the generation 1 FDMTP loader and sideloading executable. |
| SHA256 | dc666e9c148bbca5e21d8c9a97143575c075f53360f135e0191aed9e8278d396 | Encrypted update.bin payload loaded by the generation 2 FDMTP loader. |
| URL | hxxp[:]//cdns3[.]51quickfox[.]cn/2025090411/update[.]zip | Loader download URL for the archive containing the FDMTP deployment components. |
MITRE ATT&CK
T1010 · Application Window DiscoveryThe implant collects the window title of the topmost active program.T1016 · System Network Configuration DiscoveryFDMTP collects the endpoint IP address, gateway IP address, and MAC address.T1027 · Obfuscated Files or InformationThe initial JavaScript uses layered encoding and control-flow obfuscation; the second-generation .NET loader uses JieJie .NET Protector.T1033 · System Owner/User DiscoveryThe implant reports the current username to its C2 server.T1036.005 · Match Legitimate Resource Name or LocationInitial delivery infrastructure resembles legitimate QuickFox infrastructure, and the malicious JavaScript masquerades as Firebase SDK code.T1057 · Process DiscoveryThe loader checks tasklist output, and FDMTP retrieves process names and PIDs through EnumProcessByJson.T1059.003 · Windows Command ShellThe JavaScript loader invokes tasklist through cmd.exe child processes to inspect running applications.T1059.007 · JavaScriptJavaScript executed within QuickFox performs endpoint checks and downloads and launches subsequent infection components.T1071.001 · Web ProtocolsInitial downloads and implant registration use web requests to malicious delivery and staging domains.T1082 · System Information DiscoveryFDMTP collects Windows OS details, installation time, and the .NET Framework runtime version during registration.T1104 · Multi-Stage ChannelsWeb-based registration returns cluster addresses for subsequent socket-based FDMTP communications.T1105 · Ingress Tool TransferThe loader downloads update.zip, while server-delivered plugins can retrieve additional executable components.T1112 · Modify RegistryFDMTP stores compressed plugin executables under HKCU\SOFTWARE\Microsoft\IME\{Common.HostInfo.HWID} for later retrieval and execution.T1140 · Deobfuscate/Decode Files or InformationThe second-generation loader decrypts the FDMTP payload with AES-128-ECB, and implant modules and plugins are decompressed before loading.T1195.002 · Compromise Software Supply ChainThe QuickFox installer was compromised by adding downloader JavaScript to its embedded Electron renderer HTML.T1480 · Execution GuardrailsThe loader requires Windows, rejects endpoints running steam.exe, and proceeds only if a selected application process is present.T1518.001 · Security Software DiscoveryThe implant includes installed antivirus software in the host information sent to C2.T1574.001 · DLLThe article maps csmonitor.exe loading the malicious Microsoft.ServiceHosting.Tools.dll to this ID.T1620 · Reflective Code LoadingThe generation 2 loader reflectively loads the decrypted FDMTP payload, and the implant loads decompressed plugin assemblies.
