Huntress analyzed how malicious Office documents could invoke MSDT to execute code, including through RTF preview. The article details the exploit, detection and mitigations, and reports that a Microsoft patch was later validated for Windows 10 and 11.
Key points
- Huntress reproduced the Follina technique, later identified as CVE-2022-30190, using a Microsoft Word document that invoked MSDT through an external HTML reference.
- The examined payload used PowerShell commands to retrieve and decode a CAB file, then run an executable; the executable’s impact was unknown.
- Huntress found that the exploit required HTML padding and documented a shortened trigger. RTF files could also invoke it through Windows Explorer’s Preview Pane.
- The technique could execute code as the user opening or previewing the document; remote payload access could also expose NTLM hashes, according to the article.
- Huntress described detecting suspicious child processes of msdt.exe and sdiagnhost.exe, and said it was monitoring for exploit variations.
- Suggested mitigations included enabling the Office child-process Attack Surface Reduction rule or removing the ms-msdt file association.
- An update said Microsoft had released a patch and Huntress had tested and verified its effectiveness on Windows 10 and Windows 11.
Article Details
- Attack Vectors
- A Microsoft Word document references attacker-hosted HTML that invokes the ms-msdt protocol and triggers the MSDT vulnerability.
- The exploit can execute when a user opens a malicious document; an RTF file may also trigger it in Windows Explorer's Preview Pane.
- The exploit embeds PowerShell expressions in MSDT parameters and uses cmd.exe to decode and execute a payload.
- A remote-triggered connection may expose the victim's NTLM hash.
- Defensive Notes
- Apply Microsoft's patch for CVE-2022-30190; Huntress reported verifying the patch on Windows 10 and Windows 11.
- Enable the Microsoft Defender Attack Surface Reduction rule “Block all Office applications from creating child processes” in Block mode; consider Audit mode first to check for adverse effects.
- Removing the ms-msdt file-type association was described as a mitigation; back up registry settings before making changes.
- Educate users to treat unexpected document attachments cautiously, including because an RTF file may trigger through Preview Pane.
- Huntress identified child processes of msdt.exe, including sdiagnhost.exe and conhost.exe, as potential detection clues.
Indicators of compromise
| Type | Indicator | Context |
|---|---|---|
| URL | hxxps[:]//www[.]xmlformats[.]com/office/word/2022/wordprocessingDrawing/RDF842l.html | External HTML resource referenced by the exploit document; the article reports the site was no longer online at the time of analysis. |
MITRE ATT&CK
T1027 · Obfuscated Files or InformationThe sample conceals its command sequence as Base64 data nested within PowerShell expressions.T1059.001 · PowerShellPowerShell expressions embedded in the MSDT parameters are evaluated through Invoke-Expression.T1059.003 · Windows Command ShellThe decoded commands launch cmd.exe to kill msdt.exe, locate and decode a CAB file, and execute rgb.exe.T1140 · Deobfuscate/Decode Files or InformationThe command uses certutil to decode Base64 content into a CAB file before expanding it.T1187 · Forced AuthenticationThe article says a remote-triggered connection can transmit the victim's NTLM hash to an adversary.T1203 · Exploitation for Client ExecutionThe document exploits the MSDT vulnerability to execute code on the victim's system.T1204.002 · Malicious FileExecution can follow opening the malicious Word document; an RTF file may also trigger through Windows Explorer's Preview Pane.
