How to Detect RedGuard C2 Redirectors Using TLS and HTTP Indicators
Summary
A practical guide to detecting RedGuard C2 redirectors using TLS certificate details, HTTP 307 responses, and redirect locations, with a query designed to catch variants that change default settings.
Key points
- RedGuard is an open-source redirector that filters or forwards traffic between implants and command-and-control servers, helping conceal the actual C2 infrastructure.
- The guide identifies default indicators including ports 80 and 443, Aliyun TLS certificate details, configured DNS names, and redirects to 360[.]net.
- RedGuard returns HTTP 307 for temporary redirects; combining this status with response headers and certificate data can help identify servers.
- The example query uses a 307 status, an HTTP Location response header, and a TLS certificate common name matching *.aliyun[.]com.
- Because operators can change default ports, certificates, and redirect destinations, relying only on defaults may miss modified deployments.
Article Details
- Defense Focus
- Detect RedGuard C2 redirector servers by identifying their HTTP redirect behavior and TLS certificate characteristics, including configurations that differ from defaults.
- Detection Methods
- Search network and infrastructure observations for HTTP 307 responses with an HTTP Location response header and a TLS certificate common name matching *.aliyun[.]com.
- Correlate default indicators, including ports 80 and 443, DNS names, redirect location, and certificate attributes; the article cautions that these defaults are easily changed.
- Use the certificate common name and other observed certificate details to search for and filter candidate infrastructure.
- Consider response Content-Type and page-body text containing a “Temporary Redirect” HREF tag as additional query filters; Date and Content-Length are noted as changeable.
- Data Sources
- HTTP response status codes and headers, including Location, Content-Type, Date, and Content-Length
- TLS certificate fields, including common name, locality, and organization
- DNS names associated with RedGuard configurations
- HTTP response body
- Network and infrastructure scanning observations
- Rule Types
- Pseudo network-infrastructure query combining HTTP 307 status, a present HTTP Location response header, and TLS certificate common name matching *.aliyun[.]com
- Platforms
- Hunt
- Defensive Actions
- Save and annotate queries and their results for each detection variant.
- Use multiple behavioral and certificate indicators rather than relying only on default ports, redirect locations, or other defaults that operators can change.
- Treat identified redirectors as potential pivot points; blocking a redirector does not establish that the underlying C2 server has been blocked.
- Use a firewall rule on the C2 server to deny other outgoing traffic, as described in the article’s example.
Indicators of compromise
| Type | Indicator | Context |
|---|---|---|
| IPV4 | 45[.]136[.]14[.]85 | Example RedGuard server IP presented as infrastructure for the redirector. |
